GEBRUIKT: Icom IC-7300 met stille fan (september 2025)

Frequency range 9 kHz-3.7 GHz Analogue & Digital modes
10 Digital modes : TETRA,P25(Phase 1+2),DMR, Mototrbo,dPMR,NXDN,D-CR,D-STAR,Alinco,Yaesu.
Automatic detection of digital modes during scan and search.
Up to 2MHz wide digital I/Q output
Tuning steps 1Hz-999.999kHz

Analogue receive modes:
FM, FM-stereo, AM, synchronous AM, USB, LSB, CW, analogue I/Q, FM video.

Digital receive modes:
D-STAR / GMSK / AMBE DV mode only
YAESU / C4FM / AMBE+2 V/D narrow mode only
ALINCO / GMSK / AMBE EJ47 (F1E) mode only
D-CR / C4FM / AMBE+2
NXDN / C4FM / AMBE+2 6.25kHz mode only
P25 Phase 1 / C4FM / IMBE Conventional mode only
dPMR / C4FM / AMBE+2 Tier 1 only
DMR / C4FMx2 / AMBE+2 Tier 1 and Tier 2 only
TETRA direct mode (T-DM) / 1/4 shift QPSK / ACELP
TETRA traffic channel (T-TC) / 1/4 shift QPSK / ACELP (encrypted signals not supported)

Number of VFO’s – 5 –
Memory channels: 2000 (50 channels x 40 memory banks).
Banks customise from 5 to 95 channels.
Priority channel 1
Select memory channels 100 (via memory banks)
Search banks 40
Pass frequencies 1230 (30 per memory bank + 30 for VFO search)
Typical scanning speed 100 channels / steps per second (for analogue modes)
Temp range 0C+50C (32°F-122°F)Freq stability 0.1ppm (after 5 min. warm-up) or 0.01ppm with optional GPS unit.
Power requirements DC10.7V-16V (2.0A@12V)
Audio output >1.5W into 8Ohm load
Current consumption Stand-by: Approx. 200mA, Max. audio: Approx. 1.8A
Dimensions Approx. 304mm(D) x 220mm(W) x 97mm(H) (excluding projections)
Weight Approx. 5kg
Circuit type 9kHz-25MHz: Direct conversion 25MHz-3.7GHz: Double super heterodyne
Intermediate frequencies :- First: 321.95MHz / 412.05MHz Second: 45.05MHz
Demodulation method: Digital signal processing
IF filter bandwidths 200Hz, 500Hz, 1kHz, 3kHz, 6kHz, 15kHz, 30kHz, 100kHz, 200kHz (choice is mode dependent)
Automatically selected and non-changeable for digital modes.
