| Electrical Specifications 6m | |
| Frequency Range: | 50 – 50.5 MHz |
| Free Space Forward Gain: | 13.7 dBi |
| Front to Back Ratio: | 33 dB |
| 3 dB Horizontal Beamwidth: | ° |
| Polarization: | Horizontal |
| Nominal Input Impedance: | 50 Ohms |
| SWR Across Entire Band: | < 1.2 |
| Maximum Power Input: | 8000W |
| Matching Method: | Direct feed through common mode choke (current balun) |
| Connector: | 7/16 DIN |
| Mechanical Specifications 6m | |
| Number of Elements: | 9 |
| Elements Diameter: | Tapered elements. Center tube 25 mm, extensions 21 mm, 18 mm and 15 mm |
| Dipole Diameter: | Tapered dipole. Center tube 25 mm, extensions 21 mm, 18 mm and 15 mm |
| Longest Element: | 3.1 m |
| Element Mounting Position: | Below the Boom |
| Balun and Connector: | Included |
| Boom Length: | 11.7 m |
| Boom Size: | 60 x 60 mm different wall thickness |
| Number of Boom Pieces: | 8 |
| Guy rope support: | Yes, 4 x Stainless Steel 5mm rope support |
| Mounting Mast Diameter: | 43 – 60 mm 1-1/4″ – 2″ |
| Clamp and Boom Joins: | 3 x M12 Stainless Steel, Stainless Steel Sheet 3 mm |
| Element Survival Wind Speed: | 350 km/h |
| Net Weight: | 54 kg |
| Gross Weight: | 63 kg |
| Transportation Length: | 1.5 m |
