| Electrical Specifications | |
| Frequency Range: | 432 – 434 MHz |
| Free Space Forward Gain: | 16.6 dBi |
| Front to Back Ratio: | 26 dB |
| 3 dB Horizontal Beamwidth: | 29° |
| Polarization: | Vertical |
| Nominal Input Impedance: | 50 Ohm |
| Maximum SWR at any freq.: | 1 : 1.2 |
| Maximum Power Input: | More than 500 W |
| Matching Method: | Direct feed through current balun. |
| Connector: | “N” |
| Mechanical Specifications | |
| Boom length: | 3 m |
| Boom Diameter: | 30 mm |
| Longest element: | 340 mm |
| No. of elements: | 14 |
| Turning radius: | 1.6 m |
| Mounting Mast Diameter: | 43 – 70 mm |
| Survival Wind Speed: | 150 km/h |
| Weight: | 2.5 kg |
