| Electrical Specifications 4 m | |
| Frequency Range: | 70 – 70.5 MHz |
| Free Space Forward Gain: | 12.6 dBi |
| Front to Back Ratio: | 30 dB |
| 3 dB Horizontal Beamwidth: | 43.5° |
| Polarization: | Horizontal |
| Nominal Input Impedance: | 50 Ohms |
| SWR Across Entire Band: | < 1.2 |
| Maximum Power Input: | 700 W |
| Matching Method: | Direct feed through common mode balun |
| Connector: | “N” |
| Mechanical Specifications 4m | |
| Number of elements: | 7 |
| Element Diameter: | Tapered elements. Center tube 12mm, outer 10mm |
| Longest element: | 2.2 m |
| Element Mounting Position: | Below the Boom |
| Boom Length: | 5.85 m |
| Boom Size: | 40 x 40 mm |
| Number of Boom Pieces: | 4 |
| Guy rope support: | Yes – Included |
| Mounting Mast Diameter: | 1-1/4″ – 2-3/4″ 43 – 70 mm |
| Survival Wind Speed: | 150 km/h |
| Transportation Length: | 1.49 m |
| Antenna Weight: | 10 kg |
Â
4m Super Yagi Antenna PA70-7-6. Radiation Pattern. Extra LOW Side lobes.
Â
4m 70 MHz antenna. Dipole, balun and connector holder view on PA70-7-6 Low Noise Antenna.
Â
Low noise pickup 4m 70MHz Yagi Antenna PA70-7-6 Bracket Guy Rope Support view.
