| Electrical Specifications 4 m | |
| Frequency Range: | 70 – 70.5 MHz |
| Free Space Forward Gain: | 10.3 dBi |
| Front to Back Ratio: | 28 dB |
| 3 dB Horizontal Beamwidth: | 52° |
| Polarization: | Horizontal |
| Nominal Input Impedance: | 50 Ohms |
| SWR Across Entire Band: | < 1.2 |
| Maximum Power Input: | 700 W |
| Matching Method: | Direct feed through common mode balun |
| Connector: | “N” |
| Mechanical Specifications 4m | |
| Number of elements: | 5 |
| Element Diameter: | Tapered elements. Center tube 12 mm, outer 10 mm |
| Longest element: | 2.2 m |
| Element Mounting Position: | Below the Boom |
| Boom Length: | 2.93 m |
| Boom Size: | 20 x 20 mm |
| Number of Boom Pieces: | 2 |
| Mounting Mast Diameter: | 1-1/4″ – 2-3/4″ 43 – 70 mm |
| Survival Wind Speed: | 150 km/h |
| Transportation Length: | 1.49 m |
| Antenna Weight: | 3 kg |
