| Electrical Specifications | |
| Frequency Range: | 432 – 436 MHz |
| Free Space Forward Gain: | 20.1 dBi |
| Front to Back Ratio: | 31 dB |
| 3 dB Horizontal Beamwidth: | 20° |
| Polarization: | Horizontal |
| Nominal Input Impedance: | 50 Ohm |
| Maximum SWR at any freq.: | 1 : 1.2 |
| Maximum Power Input: | More than 500 W |
| Matching Method: | Direct feed through current balun. Teflon RG-142 cable |
| Connector: | “N” Teflon |
| Mechanical Specifications | |
| Boom length: | 8 m |
| Boom: | Square 40mm. Different wall thickness |
| Longest element: | 340 mm |
| No. of elements: | 29 |
| Turning radius: | 4.5 m |
| Mounting Mast Diameter: | 43 – 70 mm |
| Survival Wind Speed: | 120 km/h |
| Weight: | 9 kg |
