| Electrical Specifications | |
| Frequency Range: | 2300 – 2340 MHz |
| Free Space Forward Gain: | 19.2 dBi |
| Front to Back Ratio: | 30 dB |
| 3 dB Horizontal Beam width: | 20.6° |
| 3 dB Vertical Beam width: | 21.2° |
| Polarization: | Horizontal |
| Nominal Input Impedance: | 50 Ohms |
| SWR Across Entire Band: | < 1.35 |
| Maximum Power Input: | 250 WÂ |
| Matching Method: | RG142 Teflon Voltage Balun 1:4 |
| Connector: | “N” |
| Mechanical Specifications | |
| Number of Elements: | 31 |
| Radome Length: | 1400 mm |
| Overall Length: | 1440 mm |
| Mounting Mast Diameter: | 32 – 50 mm 1″ – 1-1/2″ |
| Survival Wind Speed: | 120 km/h |
| Net Weight: | 1.85 kg |
| Gross Weight: | 3.25 kg |
| Transportation Length: | 1.5 m |
