| Electrical Specifications | |
| Frequency Range: | 144 – 145 MHz |
| Free Space Forward Gain: | 15.72 dBi |
| Front to Back Ratio: | 32 dB |
| 3 dB Horizontal Beamwidth: | 32.3° |
| G/T | -1.75 |
| Nominal Input Impedance: | 50 Ohm |
| SWR Across Entire Band: | < 1.2 |
| Maximum Power Input: | 1500W |
| Matching Method: | Direct feed through RG142 teflon current balun. |
| Connector: | “N” |
| Mechanical Specifications | |
| Boom length: | 7 m |
| Boom : | 40×40 mm + 30×30 + 20x20mm |
| Element Diameter: | All elements 8 mm Aluminum tube. Dipole 8 mm hard Copper tube. |
| No. of elements: | 12 |
| Element position: | Facing to the Earth |
| Mounting Mast Diameter: | 1-1/4″ – 2-3/4″ 43-70 mm |
| Survival Wind Speed: | 150 km/h |
| Transportation Length: | 1.49 m |
| Net Weight: | 10.4 kg |
TANTÂ G/T -1.75:
